| Specification | |
| Boiler heating capacity | from 1 to 400 kW |
| Built-in filter | yes |
| Calibration capability | yes |
| Consumption (l/h) | from 1 to 50 |
| Consumption (l/min) | from 0.0166 to 0.833 |
| Current consumption at 12 V (not more) | 50 mA |
| Current consumption at 24 V (not more) | 25 mA |
| Display/counting device | yes |
| Engine power | from 1 to 80 kW |
| Engine running time | yes |
| Error | no more than 1% |
| Impulse type | normalized |
| Impulses per liter | 200 |
| Inlet diameter | M14x1.5 |
| Maximum consumption | 50 l / h |
| Measuring chamber volume | 5 ml |
| Measuring principle | straight |
| Mesh size of the filter mesh | 0.08 mm |
| Minimum consumption | 1 l / h |
| Operating pressure | 2 bar |
| Outlet diameter | M14x1.5 |
| Pressure drop at maximum flow | 0.03 bar |
| Resource of work of a measuring chamber | 100,000 liters |
| Type of flow meter | electronic, with pulse output |
| Type of liquid | diesel fuel |
| Types of power supply | combined nutrition |
| Voltage | from 10 to 50 V |
| Working temperature | from -20 to +60 ° C |
| Вага | 0.8 kg |
27 humans watching now
- Product Code: DFM 50 (CK, C232, C485, CCAN)
-
- Availability: In Stock
- Guarantee: 12 months
Customer reviews 0 reviews
