Teltonika FMU125 tracker with real-time tracking capability supports 3G / GSM interfaces. It is suitable for both personal cars and professional use, for example, in a car fleet or a logistics company.
Dual SIM cards help reduce roaming costs. In this case, one of the cards is used in the home network, and when leaving it, the other is used.
The device supports RS485 serial communication interface as well as RS232 interface, which is widely used in automation networks.
Worldwide 3G coverage allows you to keep in touch all the time.
Energy-saving sensors and a headset can be connected via Bluetooth. Using the headset, it is possible to keep in touch with the fleet staff, which prevents inappropriate calls, as well as to update the firmware and configuration.
Connecting a CAN adapter allows you to read data from different types of vehicles - trucks, cars, special vehicles.
Support for the 1-Wire protocol allows you to connect a temperature sensor to monitor the conditions in which the transported cargo is located. It also helps to identify the driver using the iButton key, which prevents third parties from using the car.
Functionality
- Accelerometer sensor.
- 4 sleep modes. Among them there is GPS mode, online sleep mode (keeping connection with the server), as well as very deep sleep with minimized power consumption (less than 6 mA when connected to the onboard network).
- Traffic accidents and towing detection (the latter helps to prevent vehicle theft).
- GPS fuel calculation option.
- GSM signal interruption notification.
- Backup battery.
- Auto-geofencing; 50 geofences in the form of a circle or rectangle.
- Time synchronization capability using NTP and NITZ protocols in case of instability or loss of GNSS connection.
- Overspeed alert.
- Redundant idle warning.
- Fuel monitoring: LLS (analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle.
Documentation
Drivers
Certificates
| Specification | |
| GPS module | 33/99 data collection channels
Sensitivity -110 dBm |
| Humidity | 5% to 95% non-condensing |
| Accuracy | < 3 m |
| Coordinate time | Hot start <1 s
Warm start <25 s Cold start <35 s |
| Data channels | UG96: HSUPA: Max. 5.76Mbps
UMTS: Max. 384 Kbps (DL) / Max. 384 Kbps (UL) GPRS: Max. 107Kbps (DL) /Max. 85.6Kbps (UL) SMS (text / data) |
| Technology | 3G(UMTS/HSPA)/2G(GSM/GPRS)/GNSS/BLUETOOTH |
| Capacity built-in battery | 170 мAh Li-Ion battery 3.7 В (0.63 Wh) |
| Power supply voltage | 10 - 30 V with overvoltage protection |
| Interfaces | Digital input: 1
Digital output: 1 Analog input: 1 CAN adapter inputs: 1 1-Wire: 1 RS232: 1 RS485: 1 GNSS antenna: Internal GSM antenna: Internal USB: 2.0 Micro-USB Indication: 2 LED status indicators SIM: 2x SIM Card (Dual-SIM) |
| Water and dust protection | IP41 |
| Memory | 128MB |
| Bluetooth | Specification 4.0 + LE
Supported peripherals: temperature and humidity sensor, OBDII dongle, Inateck barcode scanner, support for universal BLE sensors |
| Weight, g | 55 g |
| Operating temperature | -40 °C to +85 °C |
| Dimensions (W x D x H) | 65 x 56.6 x 20.6 mm |
-
