Teltonika FMB920 is an intelligent tracker designed to determine the location of various types of vehicles. The ultra-compact Teltonika FMB920 is equipped with a microSD memory card, Bluetooth V3.0, built-in battery and an IP54 protection case.
The vehicle location controller has built-in GNSS GNG and GSM antennas with high gain. A backup battery is included. The device is used in insurance telematics, car rental, when searching for stolen vehicles, public security, delivery, taxi services, logistics companies and other fields.
With I / O interfaces, the use case can be greatly expanded. Using a digital input, the ignition is controlled, the status of the alarm status, doors are checked. Via the digital output, the car remote control is activated. The device is easy to install even in hard-to-reach areas.
Specifications
The multifunctional "FMB920" GPS / GLONASS terminal has a lot of interesting possibilities. Let's consider them in more detail:
- The tracker has a rechargeable battery.
- FMB900 saves all data to microSD when moving in areas without GSM.
- The digital output is controlled by SMS and PC configurator.
- Accelerated cold start.
- Online tracking.
- The location controller is able to economically use GPRS traffic thanks to the smart GPRS connection algorithm.
- The process of identifying actions is performed from inputs / outputs and by means of notification via GPRS or SMS.
- In roaming, it works with the best GSM operators.
- There is an Auto Geofencing and Towing Detection function to prevent vehicle theft.
- The presence of the Deep Sleep mode (Deep sleep) will minimize power consumption (less than 2 mA).
- You can update software and device settings via GPRS.
- Data collection is carried out in a smart way.
- High degree of track accuracy even when used in densely built terrain.
- The device is equipped with high gain internal GNSS and GSM antennas.
- You can make settings via Bluetooth.
- The accelerometer will detect towing.
- With smart data collection, the device uses parameters such as: time, distance, angle, ignition status and other events at the inputs / outputs.
- The built-in Bluetooth makes it possible to use a wireless headset.
- For the safety of the driver and prevention of accidents, the device allows making calls via a Bluetooth headset.
- The ultra-compact device is easy and simple to install, but difficult to find.
- Protection against unauthorized shutdowns is provided in the form of a one-piece cable.
- In the event of an accident, the device instantly transmits an emergency message to the server, which saves the lives of affected people.
- The controller independently detects malfunctions and reports it.
- Thanks to the certified IP54 case, the device is reliably protected from dust and moisture ingress.
- Teltonika FMB900 can be installed on vehicles with increased safety requirements.
- The configuration is done using secure SMS commands and configuration.
- The use of a digital output will allow the vehicle to be immobilized remotely.
Connection diagram
Documentation
Manual:
Drivers:
Certificate
| Specification | |
| GPS module | Number of channels 33
Sensitivity -165 dBm |
| Humidity | 5% to 95% non-condensing |
| Memory | 128 MB |
| Accuracy | < 3 m |
| GSM module | Quad-band 850 / 900 / 1800 / 1900 MHz |
| Coordinate time | “Hot” start <1 sec
Warm start <25 sec “Cold” start <35 sec |
| Data channels | GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B
SMS (text/data) |
| Technology | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS |
| Capacity built-in battery | 170 mAh Li-Ion battery 3.7 V (0.63 Wh) |
| Power supply voltage | 6 - 30 V DC with overvoltage protection |
| Interfaces | Digital input 1
Digital output 1 Analog input 1 GNSS Antenna Internal GSM antenna Internal USB 2.0 Micro-USB LED indication 2 LED status indicators SIM Micro-SIM |
| Water and dust protection | IP54 |
| Bluetooth | 4.0 + LE |
| Weight, g | 54g |
| Operating temperature | -40 °C to +85 °C |
| Dimensions (W x D x H) | 79 x 43 x 12 mm |
-
